Hugo Road Project Visualization

The following visualizations show the existing and planned roadway for Hugo Road between Park Avenue and County Road J.

The new layout will feature:

  • One standard 11-foot through lane in each direction.
  • Standard 4-foot shoulders with 1 foot of pavelement and three feet of gravel.

More information on Hugo Road resurfacing project

Graphic showing existing layout of Hugo Road with irregular shoulders and travel lanes
Existing layout: Hugo Road between Park Avenue and County Road
Graphic showing proposed layout of Hugo Road with 4 foot shoulders and 11 foot through lanes
Planned layout: Hugo Road between Park Avenue and County Road

Design files

Proposed layout files are 1-2 MB each and best viewed on desktop.
